Bright Source 600 X 600mm 40W Recessed Egdelit Ceiling Tile Panel Light, 4000K Cool White, 3600lm, Includes LED Driver, Low-Glare Ugr<19, Flicker Free
1 / 1
Bright Source 600 X 600mm 40W Recessed Egdelit Ceiling Tile Panel Light, 4000K Cool White, 3600lm, Includes LED Driver, Low-Glare Ugr<19, Flicker Free

Bright Source 600 X 600mm 40W Recessed Egdelit Ceiling Tile Panel Light, 4000K Cool White, 3600lm, Includes LED Driver, Low-Glare Ugr<19, Flicker Free

Send Inquiry

Product Description

LED Panel Light (40W)

Round Shape Recessed Mounted Edge-lit Ceiling Light

Bright Source Recessed Edgelit Ceiling Tile Panel Light

Technical Specifications

Item NO. RLT-P-600*600-40W
Light Source LED
Housing Material Aluminium, Plastic, PMMA
Emitting Color Warm White, Cool White, Pure White, White
Dimmable Without Dimmable
Appearance Round
Base Material Metal
Certification CE, RoHS, ISO9001, SAA, CCC, SASO, VDE
Voltage 85-265V, 220-240V, 110-240V, 175-265V
Beam Angle 120°
Color Temperature 3000K, 4000K, 6500K, 5000K
Wattage Options 6W / 9W / 12W / 18W / 24W / 40W
Transport Package Carton

Product Overview

This edge-lit LED panel light features a high-lumen-efficiency light source combined with a highly uniform Light Guide Plate (LGP) and a premium quality driver. Key performance advantages include high luminous efficacy (up to 130lm/w), excellent light uniformity of over 90%, and outstanding overall cost-efficiency.

These panel systems are classified into distinct configurations according to sizing, lumen yield, and power ratings. Specialized panel configurations are also available, including low-glare options (UGR<19), IP65-rated wet-location panels, CCT & Wattage switchable versions, and custom-dimensional panels.

Key Applications

Commercial & Exhibition Sites
Hotels & Shopping Malls
Conference & Meeting Rooms
Hospitals & Medical Centers
Offices & Residences
Schools & Universities

Frequently Asked Questions

What are the benefits of Edge-lit LED Panel Lights?
Edge-lit LED panels position the LEDs around the frame of the fixture, shining sideways into a light guide plate (LGP). This yields extremely uniform illumination (over 90% uniformity) without hotspots or dark areas, maintaining a very thin and modern aesthetic.
What does UGR<19 mean and why is it important?
UGR stands for Unified Glare Rating. A rating of less than 19 (UGR<19) indicates the light source is engineered to prevent visual glare discomfort, which is particularly crucial for reading, focusing, and productivity in schools, offices, and study areas.
Can these LED panel lights operate on different voltages?
Yes, our LED panels are designed to support a wide range of input voltages (85-265V, 110-240V, and 220-240V) to comply with electrical safety grids across different regional standards globally.
What certifications do these ceiling lights possess?
These panel lights conform to multiple international safety and quality standards, carrying certifications such as CE, RoHS, ISO9001, SAA, CCC, SASO, and VDE.
Are there dimming or color-temperature changing options?
While the base configuration is non-dimmable, we offer upgrade configurations including CCT (Color Temperature) & Wattage switchable panels to tailor the setup to your specific spatial requirements.
